LiFePO4 battery pack 48V 50Ah

-
Model Number:LiFePO4
Type:Li-Ion, LiFePO4, LiFePO4
Nominal Capacity::Customized
Voltage:12V/24V/48V
Application::UPS,Solar ,EV,Power Supply
Size:Customized
lithium rechargeable battery::Deep Cycle lithium rechargeable battery
48V 50Ah lithium battery LiFePO4 battery pack for telecommunication base station, electric motorcycle

Komentar

Posting Komentar

Postingan populer dari blog ini

Lifepo4 Battery 12v 100ah

-
Gambar
Item 12v 100ah lifepo4 battery pack   Part No.:   LiFePO4 battery   Voltage Nominal   12.8V (Customized ) Capacity Nominal 100AH Max  Discharge Current   10 0A Or Customized  Max Charge Current   6 0A Or Customized  Weight 15kg Or Customized  Dimension 330*165*219mm Or Customized  Operating Temperature Range Charge:0 to +60°C Discharge: -20 to +60 ℃ Life Cycle   More than 2000times (100%DOD) Package   ABS/Metal Case  Or Customized Customized S hell, Size, Weight, Color, Label, Current, Bluetooth, LED Display, Technology,etc can be customized
Baca selengkapnya
-
Electrical Characteristics Model 48V 100Ah (Customizable LCD) Energy 4800Wh Internal Resistance ≤100mΩ Cycle Life ≥2000 cycles @1.0C 100%DOD Months Self Discharge <3% Standard Charge Charge Voltage 53.2~54V Charge Mode 0.2C to 54V, then 54V,charge current to 0.02C (CC/CV) Charger Current 20A Max. Charge Current 50A Charge Cut-off Voltage 57.6±0.2V Standard Discharge Continuous Current 20A Max continuous discharge current 50A Discharge Cut-off Voltage 37.5V Environmental Charge Temperature 0 ℃ to 45 ℃ (32℉ to 113℉) @60±25% Relative Humidity Discharge Temperature -20 ℃ to 60 ℃ (-4℉ to 140℉) @60±25% Relative Humidity Storage Temperature 0 ℃ to 40 ℃ (32℉ to 104℉) @60±25% Relative Humidity Mechanical Cell & Method 3.2V50Ah 15S2P Shell material iron Dimensions 442*410*221mm Weight (lbs./kg.) Approx: 63kg Gravimetric specific energy 90.5WH/KG
Baca selengkapnya

LiFePO4 Battery Pack 12v 120ah Rp. 1.500.000,- / Set

-
Gambar
Cell Chemistry LiFePO4 Nominal Voltage 12V Ampere-hour Capacity 120AH Cycles @ 100% DOD More than 2000cycles DOD100% @1.0C Weight 15kg or 33 lbs or customizable Dimension 406*174*207mm, 15.98*6.85*8.15 in Case Material ABS or Metal, or customizable Charge Temperature 0°C to 55°C Discharge Temperature -20°C to 65°C Max charging current 20A or customizable Max discharging current 120A or customizable
Baca selengkapnya
